Industrial Magnetics FXR Permanent Rare-Earth Lifting Magnet for Round Material, 1650 lbs./750 kg. Load Limit - FXR1650

Brand:   Industrial Magnetics
SKU:
FXR1650
ID:
353627
Load Limit 1650 lbs. / 750 kg.
Overall Height 10.3"
Overall Length 14.2"
callling
$2,995.00
Current Stock:
Adding to cart… The item has been added

Industrial Magnetics

Industrial Magnetics FXR Permanent Rare-Earth Lifting Magnet for Round Material, 1650 lbs./750 kg. Load Limit - FXR1650


These on/off permanent lifts offer strength in a lightweight, compact package. Each line of lifting magnets in the FX family of products has been specifically designed for maximum performance by user application. The size, shape and dimension of the parts you'll primarily be lifting - whether flat, curved, or circular-shaped - will determine the best FX lift magnet for you.


On all magnets in the series, the unique handle design only requires a 90° rotation to either engage or disengage the magnet (versus the 120° or even 180° required on most on/off lifting magnets), making it easy for operators to use in applications where the magnet is lifting something from inside a bin or a deep trough. The handle also features a positive lock-on/lock-off mechanism that requires the operator to manually switch between the two states. This prevents the handle from being turned only partially on, or from being accidentally bumped to the "off" position and dropping the load pre-maturely.


FXR PERMANENT LIFTING MAGNETS for Round Material

FXR - Mostly round/curved surfaces such as shafts, thick wall pipe, billets and occasional flat material


We recommend the FXR for when you’re mostly lifting round/curved surfaces such as shafts, thick walled pipe, or billet, but occasionally need to lift flat material. Specially designed pole shoes provide a deep penetrating magnetic field and part stability.


Features:

  • On/Off, Rare-Earth Permanent Magnet
  • On/Off handle only requires 90° rotation and locks at both on/off positions
  • Durable, recessed metal name plates, not stickers
  • Corrosion resistant, plated-magnet surface
  • Heat resistant up to 180°F (82°C)
  • 3:1 Design Factor
  • 2018 ASME B30.20 BTH-1 Design Category B, Service Class 3
  • Manufactured in Germany


Specifications:

Item Number FXR1650
Working Load Limit 1650 lbs. / 750 kg.
Overall Height 10.3"
Overall Length 14.2"
Magnet Height 5.6"
Magnet Width 6.7"
Magnet Length 13"
Handle Length 10.2"
Bail Thickness 0.8"
Bail Height 3"
Bail Width 2.3"
Weight 108 lbs.


View more Specifications & Information


See all Industrial Magnetics FXR Permanent Rare-Earth Lifting Magnets for Round Material
