Kennametal NRD3031R KC5010 Carbide Grooving Insert TiAlN Finish, RH, 1.58mm Cutting Width, 3.18mm Max Depth, Series Top Notch 1818860 - 00499319
Brand: Kennametal- SKU:
- 00499319
- ID:
- 649526
$45.27
Kennametal NRD3031R KC5010 Carbide Grooving Insert TiAlN Finish, RH, 1.58mm Cutting Width, 3.18mm Max Depth, Series Top Notch
Manufacturer Part #: 1818860
S/N: 00499319
UNSPSC: 23242105
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Insert Style | NRD |
| Cutting Width (Decimal Inch) | 0.0622 |
| Cutting Width (mm) | 1.58 |
| Insert Hand | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.1252 |
| Maximum Depth of Cut (mm) | 3.18 |
| Insert Material | Carbide |
| Manufacturer Grade | KC5010 |
| Full Radius | Yes |
| Corner Radius (Decimal Inch) | 0.0311 |
| Corner Radius (mm) | 0.79 |
| Rake | Neutral |
| Insert Size | 3031 |
| Material Grade | C3, C4 |
| Maximum Depth Of Cut Range (Decimal Inch) | 0.1000 to 0.1500 |
| Maximum Depth Of Cut Range (mm) | 3.00 to 4.00 |
| Multi-use Tool | No |
| Series | Top Notch |
| Coating Process | PVD |
| UNSPSC Code | 23242105 |
| MSC/Manufacturer Number | NRD3031R/L |
| Insert Height (Decimal Inch) | 0.3440 |
| Included Angle Degree | 55 |
| Coating/Finish | TiAlN |
