Kennametal CPGT3252HP KC5010 Carbide Turning Insert TiAlN Finish, Neutral, 9.67mm Long, 3/8" Inscribed Circle, 1/32" Corner Radius, 80° Diamond, Series Screw-On 1785480 - 01402346
Brand: Kennametal- SKU:
- 01402346
- ID:
- 671122
$35.37
Kennametal CPGT3252HP KC5010 Carbide Turning Insert TiAlN Finish, Neutral, 9.67mm Long, 3/8" Inscribed Circle, 1/32" Corner Radius, 80° Diamond, Series Screw-On
Manufacturer Part #: 1785480
S/N: 01402346
UNSPSC: 23242105
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Relief Angle | 11 |
| Insert Style | CPGT |
| Corner Radius (Inch) | 1/32 |
| Corner Radius (Decimal Inch) | 0.0313 |
| Included Angle | 80 |
| Manufacturer Grade | KC5010 |
| Coating/Finish | TiAlN |
| Wiper Edge | No |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 5/32 |
| Insert Thickness (Decimal Inch) | 0.1563 |
| Series | Screw-On |
| Inscribed Circle (Inch) | 3/8 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Insert Material | Carbide |
| Insert Shape | Diamond |
| Number Of Cutting Edges | 2 |
| Insert Shape Code | C |
| Hole Diameter (Decimal Inch) | 0.1732 |
| Hole Diameter (Mm) ( - 0 Decimals) | 4.40 |
| Maximum Depth of Cut (mm) | 1.25 |
| Maximum Depth of Cut (Decimal Inch) | 0.0492 |
| Insert Holding Method | Screw |
| Width (Inch) | 3/8 |
| Clearance Code | P |
| Tolerance Code | G |
| Coating Process | PVD |
| Length Range (Decimal Inch) | 0.3000 - 0.4000 |
| Rake | Positive |
| Insert Length (mm) | 9.67 |
| Insert Length (Decimal Inch) | 0.3808 |
| Primary Workpiece Material | Steel, Stainless Steel, Superalloys & Titanium |
| Primary Workpiece Material Code | P, M, S |
| Secondary Workpiece Material Code | N, P, S |
| Standards | ANSI, ISO |
| Manufacturers Catalog Number | 1785480 |
| Material Grade | C3, C4 |
| Coating Classification | PVD |
| Chip Breaker | HP |
| Rake Angle | 15 |
| Cutting Edge Style | Honed |
| Industry Standard Number | CPGT3252HP |
| Width (Decimal Inch - 4 Decimals) | 0.375 |
| Multi-Use Tool | Yes |
| Full Radius | No |
| Multi-Use Application | Turning, Facing, Boring |
| UNSPSC Code | 23242105 |
| Insert Size Code | 3252 |
