Kennametal LT16ELAG60 KC5025 Carbide Laydown Threading Insert TiAlN Finish, LH External Partial Profile 60° Thread, 48-8 TPI, 3/8" Inscribed Circle, 3.44mm Thick 1743702 - 03573904
Brand: Kennametal- SKU:
- 03573904
- ID:
- 665265
$53.25
Kennametal LT16ELAG60 KC5025 Carbide Laydown Threading Insert TiAlN Finish, LH External Partial Profile 60° Thread, 48-8 TPI, 3/8" Inscribed Circle, 3.44mm Thick
Manufacturer Part #: 1743702
S/N: 03573904
UNSPSC: 23291804
UPC: 662497163141
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Insert Style | 16EL |
| Insert Material | Solid Carbide |
| Manufacturer Grade | KC5025 |
| Material Grade | C2, C6 |
| Threads Per Inch | 48-8 |
| Thread Type | External |
| Pitch (mm) | 0.50 to 3.00 |
| Insert Hand | Left Hand |
| Thickness (mm) | 3.44 |
| Coating Process | PVD |
| Inscribed Circle (mm) | 9.53 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Inscribed Circle (Inch) | 3/8 |
| Corner Radius (Decimal Inch) | 0.0031 |
| Corner Radius (mm) | 0.08 |
| Hole Diameter (Mm) ( - 0 Decimals) | 3.94 |
| Hole Diameter (Decimal Inch) | 0.1551 |
| Coating Classification | Kenna Perfect |
| Thickness (Decimal Inch - 4 Decimals) | 0.1430 |
| Coating/Finish | TiAlN |
