Associated Spring Raymond 2" Hole Diam, 1" Rod Diam, 4-1/2" Free Length, Red Die Spring 999 Lb Max Deflection, 1.67" Max Deflection, Medium Heavy Duty, Chromium Alloy Steel 104-818 - 07662190
Brand: Associated Spring Raymond- SKU:
- 07662190
- ID:
- 443592
$73.30
Associated Spring Raymond 2" Hole Diam, 1" Rod Diam, 4-1/2" Free Length, Red Die Spring 999 Lb Max Deflection, 1.67" Max Deflection, Medium Heavy Duty, Chromium Alloy Steel
Manufacturer Part #: 104-818
S/N: 07662190
UNSPSC: 23153000
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Hole Diameter (Inch) | 2 | ||
| Hole Diameter (Decimal Inch) | 2.0000 | ||
| Free Length (Inch) | 4-1/2 | ||
| Color | Red | ||
| Wire Shape | Trapezoidal | ||
| Material | Chromium Alloy Steel | ||
| Rod Diameter (Decimal Inch) | 1.0000 | ||
| Maximum Deflection Load (Lb.) | 999.00 | ||
| Maximum Deflection (Decimal Inch) | 1.6700 | ||
| Spring Rate | 600.00 | ||
| Standards | ANAB Accredited, ISO 9001 | 2008 Certified, ISO/TS 16949 | 2009 Certi ed, TUV Rheinland Registered |
