Sandvik Coromant Turning Inserts, Insert Style: CNGG, Insert Size: 432, Material: Carbide, Inscribed Circle (Decimal Inch): 0.5, Thickness (Decimal Inch): 0.1875, Corner Radius (Decimal Inch): 0.0313 8003600 - 10454478
Brand: Sandvik Coromant- SKU:
- 10454478
- ID:
- 674092
$31.20
Sandvik Coromant Turning Inserts, Insert Style: CNGG, Insert Size: 432, Material: Carbide, Inscribed Circle (Decimal Inch): 0.5, Thickness (Decimal Inch): 0.1875, Corner Radius (Decimal Inch): 0.0313
Manufacturer Part #: 8003600
S/N: 10454478
UNSPSC: 23000000
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Relief Angle | 0 |
| Insert Style | CNGG |
| Corner Radius (Decimal Inch) | 0.0313 |
| Included Angle | 80 |
| Manufacturer Grade | S205 |
| Coating/Finish | TiCN, Al2O3, TiN |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 3/16 |
| Insert Thickness (Decimal Inch) | 0.1875 |
| Series | T-Max P |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Insert Material | Carbide |
| Insert Shape | Diamond |
| Insert Shape Code | C |
| Insert Holding Method | Clamp, Screw |
| Clearance Code | N |
| Tolerance Code | G |
| Coating Process | CVD |
| Primary Workpiece Material | Superalloy, Titanium |
| Iso Code | CNGG 12 04 08-SGF S205 |
| Manufacturers Catalog Number | CNGG 12 04 08-SGF S205 |
| Chip Breaker | SGF |
| UNSPSC Code | 23242105 |
| Insert Size Code | 432 |
