Destaco 697 Lb Holding Capacity, Vertical Handle, Manual Hold Down Toggle Clamp 159° Handle Movement, 89° Bar Opening, Solid Bar, Flanged Base, Oxide Finish, Forged Alloy Steel 5105-R - 30645147
Brand: Destaco- SKU:
- 30645147
- ID:
- 441393
$131.82
Destaco 697 Lb Holding Capacity, Vertical Handle, Manual Hold Down Toggle Clamp 159° Handle Movement, 89° Bar Opening, Solid Bar, Flanged Base, Oxide Finish, Forged Alloy Steel
Manufacturer Part #: 5105-R
S/N: 30645147
UNSPSC: 31162902
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Handle Orientation | Vertical |
| Bar Style | Solid |
| Base Style | Flanged |
| Bar End Type | Closed |
| Holding Capacity (N) | 3100.00 |
| Holding Capacity (Lb.) | 696.91 |
| Length Distance Between Mount Holes (mm) | 25.40 |
| Length Distance Between Mount Holes | 1in, 25.4mm |
| Length Distance Between Mount Holes (Inch) | 1.0 |
| Width Distance Between Mount Holes (mm) | 37.08 |
| Width Distance Between Mount Holes | 1.46in, 37.08mm |
| Width Distance Between Mount Holes (Decimal Inch) | 1.4600 |
| Height Under Bar (Decimal Inch) | 2.5400 |
| Height Under Bar (mm) | 64.52 |
| Overall Length (mm) | 104.90 |
| Overall Length (Decimal Inch) | 4.1300 |
| Overall Height (Decimal Inch) | 6.5400 |
| Overall Height (Mm - 5 Decimals) | 166.12 |
| Base Length (mm) | 41.15 |
| Handle Style | Straight |
| Material | Forged Alloy Steel |
| Handle Material | Forged Alloy Steel |
| Handle Color | Red |
| Mounting Hole Diameter (mm) | 6.60 |
| Mounting Hole Diameter (Decimal Inch) | 0.2600 |
| Bar Opening (Degrees) | 89 |
| Handle Movement (Degrees) | 159 |
| Bar Width (mm) | 12.95 |
| Bar Width (Decimal Inch) | 0.5100 |
| Bar Thickness (mm) | 14.22 |
| UNSPSC Code | 31162902 |
| Bar Thickness (Decimal Inch) | 0.5600 |
| Front Of Base To Toggle Tip | 2.51in |
| Includes | Toggle Lock Plus |
| Front of Base To Tip Of Toggle Bar (Decimal Inch) | 2.5100 |
| Front of Base To Tip Of Toggle Bar (mm) | 63.75 |
| Number Of Mounting Holes | 4 |
| Finish Coating | Oxide |
