Sumitomo 4NCCNGA432 BNC2010 PCBN Turning Insert 1/2" Inscribed Circle, 1/32" Corner Radius, 80° Diamond 166QEKG - 59098376
Brand: Sumitomo- SKU:
- 59098376
- ID:
- 677871
$162.05
Sumitomo 4NCCNGA432 BNC2010 PCBN Turning Insert 1/2" Inscribed Circle, 1/32" Corner Radius, 80° Diamond
Manufacturer Part #: 166QEKG
S/N: 59098376
UNSPSC: 23242105
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| ANSI Insert Code | CNGA432 |
| ISO Insert Code | CNGA120408 |
| Relief Angle | 0 |
| Insert Style | CNGA |
| Corner Radius (Inch) | 1/32 |
| Corner Radius (Decimal Inch) | 0.0315 |
| Included Angle | 80 |
| Manufacturer Grade | BNC2010 |
| Coating/Finish | TiCN |
| Insert Thickness (Inch) | 3/16 |
| Insert Thickness (Decimal Inch) | 0.1875 |
| Series | C |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Insert Material | PCBN |
| Insert Shape | C - Diamond (Rhombic) 80-Deg |
| Grade Characteristics | Hardened Materials (H) - High Wear Resistance to Moderate Wear-Resistance and Toughness |
| Number Of Cutting Edges | 4 |
| Side Clearance | Negative |
| Insert Shape Code | C |
| Hole Diameter (Decimal Inch) | 0.2031 |
| Insert Holding Method | Clamp, Pin |
| Clearance Code | N |
| Tolerance Code | G |
| Coating Process | PVD |
| Rake | Negative |
| Insert Length (Decimal Inch) | 0.0945 |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | H |
| Iso Code | 4NC-CNGA120408 |
| Standards | ANSI, ISO 13399 |
| Chip Breaker | A |
| ANSI Size Code | 432 |
| ISO Size Code | 120408 |
| UNSPSC Code | 23242105 |
| Insert Size Code | 432 |
