Seco Tools CNMP432-MF1 CP200 Carbide Turning Insert TiAlN/TiN Finish, 1/2" Inscribed Circle, 1/32" Corner Radius, 80° Diamond 00054151 - 67857458
Brand: Seco Tools- SKU:
- 67857458
- ID:
- 676534
$24.96
Seco Tools CNMP432-MF1 CP200 Carbide Turning Insert TiAlN/TiN Finish, 1/2" Inscribed Circle, 1/32" Corner Radius, 80° Diamond
Manufacturer Part #: 00054151
S/N: 67857458
UNSPSC: 23242105
(Minimum Order Quantity=10)
(Please order in multiples of 10)
Specifications:
| ANSI Insert Code | CNMP432 |
| ISO Insert Code | CNMP120408 |
| Relief Angle | 0 |
| Insert Style | CNMP |
| Corner Radius (Inch) | 1/32 |
| Corner Radius (Decimal Inch) | 0.0315 |
| Included Angle | 80 |
| Manufacturer Grade | CP200 |
| Coating/Finish | TiAlN, TiN |
| Wiper Edge | No |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 3/16 |
| Insert Thickness (Decimal Inch) | 0.1874 |
| Series | CNMP-MF1 |
| Inscribed Circle (Inch) | 1/2 |
| Inscribed Circle (Decimal Inch) | 0.5000 |
| Inscribed Circle (mm) | 12.70 |
| Insert Material | Carbide |
| Insert Shape | C - Diamond (Rhombic) 80-Deg |
| Chip Breaker Operation | Finishing |
| Grade Characteristics | Steel (P) - High Wear-Resistance, Stainless Steel (M) - High Wear-Resistance to Moderate Wear-Resistance and Toughness, Special, Super Alloys (S) - High Wear-Resistance to Moderate Wear-Resistance and Toughness |
| Number Of Cutting Edges | 4 |
| Side Clearance | Negative |
| Insert Shape Code | C |
| Hole Diameter (Decimal Inch) | 0.2028 |
| Maximum Depth of Cut (Decimal Inch) | 0.4764 |
| Insert Holding Method | Clamp, Pin, Lever Lock |
| Width (Inch) | 1/2 |
| Clearance Code | N |
| Tolerance Code | M |
| Coating Process | PVD |
| Length Range (Decimal Inch) | 0.5000 - 0.6000 |
| Rake | Negative |
| Insert Length (Decimal Inch) | 0.5079 |
| Primary Workpiece Material | Stainless Steel, Superalloys & Titanium |
| Primary Workpiece Material Code | P, M, S |
| Secondary Workpiece Material | Steel, Cast Iron |
| Secondary Workpiece Material Code | P, K |
| Iso Code | CNMG120408-MF1 |
| Standards | ANSI, ISO |
| Manufacturers Catalog Number | 00054151 |
| Material Grade | M01, M10, M20, S10, S20 |
| Proprietary Coating Designation | Multilayer Coating |
| Lead Angle | 80 |
| Coating Classification | PVD |
| Chip Breaker | MF1 |
| Cutting Edge Style | Honed |
| Industry Standard Number | CNMP432-MF1 |
| Width (Decimal Inch - 4 Decimals) | 0.5000 |
| Multi-Use Tool | Yes |
| Full Radius | No |
| Multi-Use Application | Boring, Facing, Turning |
| ANSI Size Code | 432 |
| ISO Size Code | 120408 |
| UNSPSC Code | 23242105 |
| Insert Size Code | 432 |
