WIDIA Spiral Flute Tap: 7/8-14 UNF, 4 Flutes, Modified Bottoming, 2B Class of Fit, High Speed Steel, Black Oxide Coated 0.71" Thread Length, 4.92" OAL, Right Hand Thread, H6, Series VTSFT-TC 6172920 - 97527238

WIDIA Spiral Flute Tap: 7/8-14 UNF, 4 Flutes, Modified Bottoming, 2B Class of Fit, High Speed Steel, Black Oxide Coated 0.71" Thread Length, 4.92" OAL, Right Hand Thread, H6, Series VTSFT-TC 6172920 - 97527238

Brand:   WIDIA
SKU:
97527238
ID:
772504
callling
$215.32
Current Stock:
Adding to cart… The item has been added

WIDIA

WIDIA Spiral Flute Tap: 7/8-14 UNF, 4 Flutes, Modified Bottoming, 2B Class of Fit, High Speed Steel, Black Oxide Coated 0.71" Thread Length, 4.92" OAL, Right Hand Thread, H6, Series VTSFT-TC

Manufacturer Part #: 6172920

S/N: 97527238

(Minimum Order Quantity=1, Package Quantity=1)

Specifications:

Thread Size (Inch)7/8-14
Thread StandardUNF
ChamferModified Bottoming
MaterialHigh-Speed Steel
Thread LimitH6
Class Of Fit2B
Coating/FinishBlack Oxide
Thread DirectionRight Hand
Coolant ThroughNo
Material ApplicationSteel, Stainless Steel, Cast Iron
Number Of Flutes4
Flute DirectionRight Hand
Threads per Inch14
Thread Length (Decimal Inch)0.7100
Overall Length (Decimal Inch)4.9200
Thread Pitch (Decimal Inch)0.0714
Material GradeWP49EG
Shank Diameter (Decimal Inch)0.7087
Tapping Depth (Decimal Inch)2.2400
Square Size (Decimal Inch)0.5710
SeriesVTSFT-TC
UNSPSC Code23241600
