Insize Dial Snap Gages

For quick Go/No-Go judgment of diameter of cylinders and shafts.
Left anvil retracting stroke: .079″.
Measuring force: 1.35-1.8lbf.
Flatness of anvil: 59µin.
Repeatability: 39µin.
Carbide measuring faces for anvils.
Front edges of anvils are chamfered for easy workpiece insertion.
Supplied with Manufacturer Inspection Certificate to DKD Germany
Dial And Digital Indicators (reading .00005" 0r .0005") are optional

For more details and Specifications on each item, click on the Item Number in the table below.

WARNING: This Product Can Expose You To Materials And/Or Chemicals Which Are Known To The State Of California To Cause Cancer And/Or Reproductive Harm.

For more info, visit www.p65warnings.ca.gov.

Item Number	Description	Price	Quantity
2186-25E	Insize Dial Snap Gage, 0-1" Range	.00016"	$ 1,091.95
2186-50E	Insize Dial Snap Gage, 1-2" Range	.00016"	$ 1,212.95
2186-75E	Insize Dial Snap Gage, 2-3" Range	.00020"	$ 1,276.95
2186-100E	Insize Dial Snap Gage, 3-4" Range	.00024"	$ 1,385.95
2186-125E	Insize Dial Snap Gage, 4-5" Range	.00024"	$ 1,456.95
2186-150E	Insize Dial Snap Gage, 5-6" Range	.00032"	$ 1,521.95
2186-175E	Insize Dial Snap Gage, 6-7" Range	.00032"	$ 1,609.95
2186-200E	Insize Dial Snap Gage, 7-8" Range	.00040"	$ 1,677.95
2186-225E	Insize Dial Snap Gage, 8-9" Range	.00040"	$ 1,787.95
2186-250E	Insize Dial Snap Gage, 9-10" Range	.00040"	$ 1,871.95
2186-275E	Insize Dial Snap Gage, 10-11" Range	.00047"	$ 1,979.95
2186-300E	Insize Dial Snap Gage, 11-12" Range	.00047"	$ 2,310.95
