Interstate High Speed Steel Hand Tap, 1-3/8 - 12 UNF, H4 Thread Limit, 6 Flutes - 42-226-1

Brand:   Interstate
SKU:
42-226-1
ID:
142210
Thread Size 1-3/8 - 12 UNF
Thread Limit H4
Flutes 6
Thread Length 3"
OAL 6-1/16"
$229.95
Current Stock:
Adding to cart… The item has been added

Value Collection Interstate

Interstate High Speed Steel Hand Tap
1-3/8 - 12 UNF, H4 Thread Limit, 6 Flutes

Bottoming Style


1-3/8 - 12 UNF H4 6-Flute Bright Finish High Speed Steel Straight Flute Standard Hand Tap, Bottoming Chamfer, Right Hand Thread, 6-1/16" OAL, 3" Thread Length, 3B


Features:

  • HSS Ground Thread for Ferrous, Nonferrous and Nonmetallic Materials.
  • These taps have one to two chamfered threads which enable them to thread closer to the bottom of a blind hole with full threads.
  • Smaller sizes may have a point. (Male center) (1-2 Pitches).
  • Bottoming chamfers are used for threading blind holes. They have 1 to 2 threads.
  • High Speed Steel (HSS) provides good wear-resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
  • Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.


Specifications:

Tap Type Standard Hand Tap
Thread Size (Inch) 1-3/8 - 12
Class of Fit 3B
Thread Limit H4
Number of Flutes 6
Chamfer Bottoming
Material High Speed Steel
Finish/Coating Bright
Thread Direction Right Hand
Through Coolant NonThrough Coolant
Thread Standard UNF
Overall Length (Inch) 6-1/16
Oversize No
Thread Length (Inch) 3



See all Interstate High Speed Steel Hand Taps


Warning Icon

WARNING: This Product Can Expose You To Materials And/Or Chemicals Which Are Known To The State Of California To Cause Cancer And/Or Reproductive Harm.
