ANSI-compliant, robust, and oh-so-tiny, the Min-E-Stop can be mounted exactly where you need it most.

The Min-E-Stop is a small emergency stop button in an aluminum enclosure with pre-wired control cable. IP-67 Rated.

Button Details:

This swiss-made emergency stop button is best in class and especially sourced for it’s low profile.

• Contact Configuration: 2 Normally Closed (alternate configurations available)
• Actuation Style: latching, twist-to-release
• Illumination: none (but available as an option).
• Rated Impulse Withstand Voltage: 4kV
• Actuating force: 17N ±4N
• IP Rating: IP67

Contact Ratings:

Double-break, gold-plated silver contact
Rated as "forced opening" per EN 60947-5-5

AC-15, as per EN IEC 60947-5-1:

• 3A @ 120VAC
• 1.5A @ 240VAC

DC-13, as per EN IEC 60947-5-1 (normally-closed contacts):

• 2.5A @ 12VDC
• 2.5A @ 24VDC
• 1.25A @ 48VDC
• 1.0A @ 60VDC

Recommended minimum operation: 1mA @ 1VDC/1VAC

Cable Details:

• Conductors: 4 x 22 AWG
• Voltage Rating: 1,000V
• Jacket: PUR
• Flexibility: very flexible
• Length: 6 ft. (extended options available)

Enclosure Details:

• Material: Cast aluminum
• Color: Black (anodized)
• IP Rating: IP67
• Cable Gland: Nickel-plated brass, IP-67 rated
• Cable Exit: 1 x left (other options available).

Illumination Specs (optional):

• LED Color: Red
• LED operating voltage: 5 … 30 VDC
• Current consumption: 9.7 …12.4 mA
