TMX 1-1/2 Inch Cutting Dia. Face Mill, 90° Cut, with .500 Pilot Arbor Mount, 3 Flutes, for TP_ 32 Style Inserts - 6-902-156

TMX 1-1/2 Inch Cutting Dia. Face Mill, 90° Cut, with .500 Pilot Arbor Mount, 3 Flutes, for TP_ 32 Style Inserts - 6-902-156

Brand:   TMX
SKU:
6-902-156
ID:
359922
callling
$243.90
Current Stock:
Adding to cart… The item has been added

TMX Toolmex

TMX 1-1/2 Inch Cutting Dia. Face Mill, 90° Cut, with .500 Pilot Arbor Mount, 3 Flutes, for TP_ 32 Style Inserts - 6-902-156

1-1/2 Inch Cutting Dia. Face Mill, 90° Cut, with .500 Pilot Arbor Mount, 3 Flutes, for TP_ 32 Style Inserts

  • General purpose 90 degree Face mills
  • Utilizes standard ANSI inserts

Specifications:

Diameter D   1-1/2
Height H

1-37/64
Arbor Hole d   1/2
a   21/32
No. of Inserts   3
Insert   TPC-43, TPU-43,
TPG-43



Tolerances
Tolerance: DØ = mm +/-0.8 mm
Tolerance: dØ = mm +0.013/-0.0 mm
Tolerance: H = mm +/-0.15 mm



See all TMX TPG Face Mills for TPG/TPU Inserts
