TMX 4-Jaw Plain Back Steel Scroll Chuck, 8in - 3-841-0800P
Brand: TMX- SKU:
- 3-841-0800P
- ID:
- 359861
| Chuck Size | 8" |
| Gripping Force | 3700 daN |
| Max RPM | 4000 RPM |
| Weight | 39 lbs. |
$1,793.05
TMX 4-Jaw Plain Back Steel Scroll Chuck, 8in
3-841-0800P
4-Jaw (2 Piece) Scroll Chuck, Steel, 8in
TMX by Toolmex MADE IN EUROPE
Precision Forged Steel
4-Jaw Scroll Chuck with Two-Piece Hard Reversible Jaws
Made in Poland, available in many sizes and configurations.
Each chuck is provided with:
- 1 Set of hard master jaws
- 1 Set of hard top reversible jaws
- 1 Chuck wrench
- 1 Set of mounting bolts
- Eye bolts for chuck sizes 15-3/4" diameter and larger
Technical Data:
  |
| Selling Unit | EA | |
| Chuck Type | Scroll | |
| Chuck Size | in | 8 |
| Body Material | Forged Steel | |
| Number of Jaws | 4 | |
| Jaw Type | 2pc | |
| Weight | lb | 39 |
| Mount Type | Back | |
| Gripping Force | daN | 3700 |
| Max RPM | RPM | 4000 |
| Diameter D | in | 7.874 |
| Recess Diameter B | in | 6.2992 |
| Recess Depth C | in | 0.1575 |
| Hole Diameter E | in | 2.1654 |
| Bolt Circle F | in | 6.9291 |
| Body Height H | in | 2.9528 |
| Jaw Height H1 | in | 1.7717 |
| Hole Thread Size S | 6xM10 |
| d1 Two-Piece Jaws | in | 0.157 - 3.54 |
| d2 Two-Piece Jaws | in | 2.83 - 6.14 |
| d3 Two-Piece Jaws | in | 5.24 - 7.87 |
| d4 Two-Piece Jaws | in | 1.97 - 5.12 |
| d5 Two-Piece Jaws | in | 4.13 - 7.48 |
