TMX SP90 D2.00-A.750/1.75-04-13, 2 Inch Diameter 90° 4 Flute High Feed Indexable Face Mill for SPKx 13 Inserts - 181-0495-00
Brand: TMX- SKU:
- 181-0495-00
- ID:
- 359907
$384.25
TMX SP90 D2.00-A.750/1.75-04-13, 2 Inch Diameter 90° 4 Flute High Feed Indexable Face Mill for SPKx 13 Inserts - 181-0495-00
SP90 D2.00-A.750/1.75-04-13, 2 Inch Diameter 90° 4 Flute High Feed Indexable Face Mill for SPKx 13 Inserts, Toolmex Palbit
- Strong Pocket design
- Wide Chip Gullets for maximum chip evacuation
- Double sided Technology
- Through Coolant
- Satin Nickel plating for longevity
Specifications:
| Number of Inserts | 4 | |
| Insert Style | SPKT/SPKW-13 | |
| Max depth of cut (a) | in | .079 |
| α° (Ramp Angle) | 1.5° | |
| Rp (Programmed Radius) | in | .098 |
| ØDc (Diameter) | in | 2.0 |
| Ød | in | .750 |
| Ødg | in | 1.772 |
| L | in | 1.75 |
