Vernon Cham-Bits

Drill, chamfer & deburr in one operation!
Drill length positioning can be varied instantly.
Patent locking device prevents any axial movement of Cham-Bit.
Single point cutter ensures concentricity.
Cutting Direction: Right Hand
Drill Not Included.

WARNING: This Product Can Expose You To Materials And/Or Chemicals Which Are Known To The State Of California To Cause Cancer And/Or Reproductive Harm.

For more info, visit www.p65warnings.ca.gov.

Item Number	Description	Price	Quantity
07-029-500	Vernon Cham-Bit, 1/8" Drill Size, .1250" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-502	Vernon Cham-Bit, #30 Drill Size, .1285" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-504	Vernon Cham-Bit, #29 Drill Size, .1360" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-508	Vernon Cham-Bit, 9/64" Drill Size, .1406" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-514	Vernon Cham-Bit, #25 Drill Size, .1495" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-520	Vernon Cham-Bit, 5/32" Drill Size, .1562" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-524	Vernon Cham-Bit, #21 Drill Size, .1590" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-528	Vernon Cham-Bit, #19 Drill Size, .1660" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-532	Vernon Cham-Bit, 11/64" Drill Size, .1719" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-534	Vernon Cham-Bit, #17 Drill Size, .1730" Decimal Diameter, 5/8" Overall Length	yes	$ 45.95
07-029-544	Vernon Cham-Bit, 3/16" Drill Size, .1875" Decimal Diameter, 3/4" Overall Length	yes	$ 48.95
07-029-548	Vernon Cham-Bit, #11 Drill Size, .1910" Decimal Diameter, 3/4" Overall Length	yes	$ 48.95
07-029-556	Vernon Cham-Bit, #7 Drill Size, .2010" Decimal Diameter, 3/4" Overall Length	yes	$ 48.95
07-029-558	Vernon Cham-Bit, 13/64" Drill Size, .2031" Decimal Diameter, 3/4" Overall Length	yes	$ 48.95
07-029-566	Vernon Cham-Bit, #3 Drill Size, .2130" Decimal Diameter, 3/4" Overall Length	yes	$ 48.95
07-029-578	Vernon Cham-Bit, B Drill Size, .2380" Decimal Diameter, 1" Overall Length	yes	$ 51.95
07-029-584	Vernon Cham-Bit, 1/4" Drill Size, .2500" Decimal Diameter, 1" Overall Length	yes	$ 51.95
07-029-586	Vernon Cham-Bit, F Drill Size, .2570" Decimal Diameter, 1" Overall Length	yes	$ 51.95
07-029-588	Vernon Cham-Bit, G Drill Size, .2610" Decimal Diameter, 1" Overall Length	yes	$ 51.95
07-029-590	Vernon Cham-Bit, 17/64" Drill Size, .2656" Decimal Diameter, 1" Overall Length	yes	$ 51.95
07-029-594	Vernon Cham-Bit, I Drill Size, .2720" Decimal Diameter, 1" Overall Length	yes	$ 51.95
07-029-600	Vernon Cham-Bit, 9/32" Drill Size, .2812" Decimal Diameter, 1" Overall Length	yes	$ 51.95
07-029-610	Vernon Cham-Bit, 5/16" Drill Size, .3125" Decimal Diameter, 1-1/4" Overall Length	yes	$ 57.95
07-029-614	Vernon Cham-Bit, P Drill Size, .3230" Decimal Diameter, 1-1/4" Overall Length	yes	$ 57.95
07-029-616	Vernon Cham-Bit, 21/64" Drill Size, .3281" Decimal Diameter, 1-1/4" Overall Length	yes	$ 57.95
07-029-622	Vernon Cham-Bit, 11/32" Drill Size, .3438" Decimal Diameter, 1-1/4" Overall Length	yes	$ 57.95
07-029-632	Vernon Cham-Bit, 3/8" Drill Size, .3750" Decimal Diameter, 1-1/4" Overall Length	yes	$ 57.95
07-029-644	Vernon Cham-Bit, 13/32" Drill Size, .4062" Decimal Diameter, 1-1/4" Overall Length	yes	$ 57.95
07-029-648	Vernon Cham-Bit, 27/64" Drill Size, .8750" Decimal Diameter, 2" Overall Length	yes	$ 57.95
07-029-650	Vernon Cham-Bit, 7/16" Drill Size, .4375" Decimal Diameter, 1-1/4" Overall Length	yes	$ 57.95
07-029-652	Vernon Cham-Bit, 29/64" Drill Size, .4531" Decimal Diameter, 1-1/2" Overall Length	yes	$ 66.95
07-029-656	Vernon Cham-Bit, 15/32" Drill Size, .4688" Decimal Diameter, 1-1/2" Overall Length	yes	$ 66.95
07-029-660	Vernon Cham-Bit, 1/2" Drill Size, .5000" Decimal Diameter, 1-1/2" Overall Length	yes	$ 66.95
07-029-662	Vernon Cham-Bit, 33/64" Drill Size, .5156" Decimal Diameter, 1-1/2" Overall Length	yes	$ 66.95
07-029-664	Vernon Cham-Bit, 17/32" Drill Size, .5312" Decimal Diameter, 1-1/2" Overall Length	yes	$ 66.95
07-029-674	Vernon Cham-Bit, 5/8" Drill Size, .6250" Decimal Diameter, 1-5/8" Overall Length	yes	$ 79.95
07-029-678	Vernon Cham-Bit, 21/32" Drill Size, .6562" Decimal Diameter, 1-5/8" Overall Length	yes	$ 79.95
07-029-682	Vernon Cham-Bit, 11/16" Drill Size, .6875" Decimal Diameter, 1-5/8" Overall Length	yes	$ 79.95
07-029-706	Vernon Cham-Bit, 7/8" Drill Size, .8750" Decimal Diameter, 2" Overall Length	yes	$ 116.95
