Eaton Cutler-Hammer NO/NC, 13mm Detection, Rectangular Shielded, Inductive Proximity Sensor 2 Wires, IP67, 20 to 264 VAC/VDC, 4-1/2 Inch Long x 1.54 Inch Wide E51ALT1 - 00330613
Brand: Eaton Cutler-Hammer- SKU:
- 00330613
- ID:
- 593788
$1,052.11
Eaton Cutler-Hammer NO/NC, 13mm Detection, Rectangular Shielded, Inductive Proximity Sensor 2 Wires, IP67, 20 to 264 VAC/VDC, 4-1/2 Inch Long x 1.54 Inch Wide
Manufacturer Part #: E51ALT1
S/N: 00330613
UNSPSC: 39122230
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Sensor Type | Inductive |
| Body Shape | Rectangular Shielded |
| Sensor Operation Output Mode | NO |
| Detection Distance (mm) | 13.00 |
| Detection Distance (Decimal Inch) | 0.5100 |
| Maximum Voltage | 20 to 264Vac/Vdc |
| Overall Length (mm) | 114.00 |
| Overall Length (Inch) | 4-1/2 |
| Overall Width (mm) | 39.00 |
| Overall Width (Decimal Inch - 4 Decimals) | 1.5400 |
| Ingress Protection Rating | IP67 |
| Overall Width/Diameter (mm) | 39 |
| Housing Material | Zinc |
| Resistance Features | Shock-Resistant, Vibration-Resistant |
| Minimum Operating Temperature | -13F |
| Maximum Operating Temperature | 158F |
| Standards | CE Listed, CSA Certified, UL Listed |
| Number Of Wires | 2 |
| Response Frequency (Hz) | 10 to 55 |
| Nema Rating | 12, 13, 3, 3S, 4, 4X, 6, 6P |
