Destaco 499 Lb Inner Hold Capacity, Horiz Mount, Air Power Hold-Down Toggle Clamp 1/8 NPT Port, 145 Max psi, 103° Bar Opening, 35.05mm Height Under Bar 807-S-RC - 57298366
Brand: Destaco- SKU:
- 57298366
- ID:
- 441667
$76.98
Destaco 499 Lb Inner Hold Capacity, Horiz Mount, Air Power Hold-Down Toggle Clamp 1/8 NPT Port, 145 Max psi, 103° Bar Opening, 35.05mm Height Under Bar
Manufacturer Part #: 807-S-RC
S/N: 57298366
UNSPSC: 31162900
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Power Type | Pneumatic | ||
| Bar End Type | Closed | ||
| Holding Capacity - Inner (N) | 2220.00 | ||
| Holding Capacity - Inner (Lb.) | 499.00 | ||
| Bar Opening (Degrees) | 103 | ||
| Bar Style | Solid | ||
| Height Under Bar (mm) | 35.05 | ||
| Height Under Bar (Decimal Inch) | 1.3800 | ||
| Length Distance Between Mount Holes (Decimal Inch) | 0.7500 | ||
| Length Distance Between Mount Holes (Inch) | 3/4 | ||
| Length Distance Between Mount Holes (mm) | 19.05 | ||
| Maximum Air Pressure (bar) | 10.00 | ||
| Maximum Mechanical Advantage | 02 | 01, 06 | 01 |
| Mounting Hole Size (Decimal Inch) | 0.2800 | ||
| Mounting Orientation | Horizontal | ||
| Outer Clamping Force (N) | 804.00 | ||
| Sensor Compatibility | Round, T-Slot | ||
| Width Distance Between Mount Holes (Decimal Inch) | 1.2500 | ||
| Width Distance Between Mount Holes (mm) | 31.75 | ||
| UNSPSC Code | 31162900 | ||
| Port Size | 1/8 NPT | ||
| Includes | Bolt Retainer | ||
| Minimum Operating Temperature F | 14 | ||
| Maximum Operating Temperature F | 194 |
