Hertel Manual Lathe Chucks, Chuck Type: Self-Centering, Nominal Chuck Size: 10, Number of Jaws: 3, Mount: Plain Back, Through-Hole Diameter (Decimal Inch): 2.9921, Body Material: Cast Iron (Semi-Steel) 1-203-1000 - 97018774

Hertel Manual Lathe Chucks, Chuck Type: Self-Centering, Nominal Chuck Size: 10, Number of Jaws: 3, Mount: Plain Back, Through-Hole Diameter (Decimal Inch): 2.9921, Body Material: Cast Iron (Semi-Steel) 1-203-1000 - 97018774

Brand:   Hertel
SKU:
97018774
ID:
450999
callling
$1,388.34
Current Stock:
Adding to cart… The item has been added

Hertel

Hertel Manual Lathe Chucks, Chuck Type: Self-Centering, Nominal Chuck Size: 10, Number of Jaws: 3, Mount: Plain Back, Through-Hole Diameter (Decimal Inch): 2.9921, Body Material: Cast Iron (Semi-Steel)

Manufacturer Part #: 1-203-1000

S/N: 97018774

UNSPSC: 31380000

(Minimum Order Quantity=1, Package Quantity=1)

Specifications:

Chuck TypeSelf-Centering
Chuck Diameter (Inch)10
Number Of Jaws4
Mount TypePlain Back
Body MaterialCast Iron
AdjustableNo
Reversible JawsReversible
Maximum Jaw Capacity (Inch)1-27/32
Jaw Height (Inch)2-9/64
Maximum Rpm2000
Axial Runout (Decimal Inch)0.0010
Radial Runout (Decimal Inch)0.0016
Body Length (Inch)3-45/64
Minimum Jaw Capacity (Inch)13/64
Through-Hole Diameter (Decimal Inch)2.9921
Warning Icon

WARNING: This Product Can Expose You To Materials And/Or Chemicals Which Are Known To The State Of California To Cause Cancer And/Or Reproductive Harm.

For more info, visit www.p65warnings.ca.gov.
