Mahr MarCator Dial Indicator, ANSI/AGD Group 1, Series B, Type B8I, 0.250" Range, 0.001" Graduation, 0-50-0 Dial Face - 2011141

Brand:   Mahr
SKU:
2011141
ID:
88098
Type B8I
Range 0.250"
Graduation 0.001"
Dial Face 0-50-0
Pointer Rotation 0.100"
Error Limit ±0.001"
$299.95
Current Stock:
Adding to cart… The item has been added

Mahr

Mahr MarCator Dial Indicator, ANSI/AGD Group 1, Series B, Type B8I, 0.250" Range, 0.001" Graduation, 0-50-0 Dial Face - 2011141

Indicator Type: B8I


Features:

  • Unit construction and removable movement save repair/cleaning time and maintenance
  • Hardened gears and stainless steel racks provide lasting protection against indicator failure due to shock or wear
  • Jeweled bearings resist friction, add to longer indicator life
  • Skeletonized, hobbed gears for more sensitive response, superior indicator accuracy with minimal hysteresis error
  • Soft tinted dials (green - inch / yellow - metric) minimize eye strain
  • Special steel alloy
  • Balanced dial hand affords no shift, precise reading
  • Controlled rack and pinion mesh eliminates slope for precise response and reading
  • Smooth adjusting bezels for easy setup
  • Positive pressure pull back spring requires less maintenance
  • Compliance with ANSI/AGD dimensional and accuracy specifications
  • These indicators are normally furnished with continuous dial (with R.C.) or + on right balance dial (w/o R.C.), lug back and .18” by .250" long contact
  • Optional Dials: balanced dial with + on left; continuous clockwise; continuous counterclockwise (Order by part number and specify dial style desired)

Standard: ANSI B89.1.1 0-1987
Dial diameter: 1.75"
Dial Color: Green


Technical Data:

Order No. Product
Type
Measuring
Range
Graduation Type of
Dial Face
Pointer
Rotation
Error Limit Error Limit over
2.5 Rotations
2011141 B8I 0.250" 0.001" 0-50-0 0.100" ± 0.001" ± 0.001"
