Mitutoyo 2-Point Inside Bore Gage for Short Length, 35-60mm - 511-767
Brand: Mitutoyo- SKU:
- 511-767
- ID:
- 399146
| Graduation | 0.01mm |
| Number Of Anvils | 6 |
| Number Of Spacers | 4 |
| Range | 35 - 60mm |
$414.70
Mitutoyo 2-Point Inside Bore Gage for Short Length, 35-60mm - 511-767
This is a compact and lightweight bore gauge due to the short length below the grip.
It offers you the following benefits:
- A long plunger stroke gives you amazing accuracy.
- Contact points are carbide giving you high durability and wear resistance.
- A large grip reduces heat transfer from the operator by 50%.
Technical Data:
- Accuracy: 2μm / .00008”
- Indication stability: 1μm / .00004”
- Graduation: 0.01mm, 0.001mm, .0005” or .0001”
Specifications
| Range | 35 - 60 mm |
| Graduation | 0.01 mm |
| No. Dial Indicator | 2046SB |
| Measuring depth | 50 mm |
| Mass | 380 |
| Number of anvils | 6 |
| Number of spacers | 4 |
| Delivered | Including box, dial indicator, plastic cover for indicator |
| Stroke of contact point | 18 - 60 mm: 1.2 mm 50 - 160 mm: 1.6 mm |
| Repeatability | 0,5 µm |
| Digital/Analog | Analog |
| Inch-Metric | Metric |
