Mitutoyo Dial Snap Meter, 1-2" Range - 523-132
Brand: Mitutoyo- SKU:
- 523-132
- ID:
- 110902
| Range | 1 - 2" |
$879.75
Mitutoyo Dial Snap Meter, 1-2" Range - 523-132
- Direct GO/NO-GO judgment for mass produced parts.
- Spindle diameter: 10.8mm (.425")
- IP protection level: 54
- Supplied in fitted plastic case.
Technical Data:
Dial indication accuracy: 1µm / .00005”
Indication repeatability: 0.4µm / .00002”
Dial reading: 0.001mm or .00005"
Flatness: 0.3µm / .000012”
Parallelism: 0.6µm / .000024” for
models up to 50mm / 2”
1µm / .00004” for models over 50mm / 2”
Measuring force: 5 - 10N (500 - 1000gf)
Specifications:
| Manufacturer Part # | 523-132 |
| Maximum Measurement (Inch) | 2 |
| Accuracy (Decimal Inch) | 0.00005 |
| Graduation (Inch) | 0.00005 |
| Anvil Type | Solid Carbide |
| Thimble Type | Friction |
| Rotating Spindle | No |
| Digital Counter | No |
| Measuring Face Material | Solid Carbide |
| Throat Depth (Mm - 2 Decimals) | 35 |
| Spindle Diameter (mm) | 10.8 |
| Spindle Diameter (Decimal Inch) | 0.425 |
| Features | Easy-to-Operate Retracting Button |
| Includes | Plastic Case |
| Coating/Finish | Hammertone; Baked Enamel |
| Country of Origin | Japan |
