TMX Bull Head Live Center, MT6, 11.50" Dia - 3-575-060P
Brand: TMX- SKU:
- 3-575-060P
- ID:
- 106902
| Morse Taper | MT 6 |
| Dia | 11.50" |
| T.I.R. | 0.002" |
| Max Speed | 1000 RPM |
| Max Workpiece Wt. | 4400 lbs. |
| Weight | 75 lbs. |
$1,695.00
TMX Bull Head Live Center, MT6, 11.50" Dia - 3-575-060P
Bull Nose & Pipe Live Center MT6
Head Diameter: 11.50in
T.I.R. .002
TMX by Toolmex MADE IN EUROPE
(Compare to Bison® Model 8825 - Series 7-575)
Three matched bearings are preloaded at the factory. This provides good thrust and radial capabilities. The bearings are protected by a special seal. The head is made of high carbon alloy steel heat treated to RC 61-6. 60 degree head angle. Centers are designed to hold pipe and hollow work.
Technical Data:
| Selling Unit | EA | |
| Item | Live Center | |
| Type | Bull Nose | |
| Morse Taper | 6 | |
| T.I.R. | 0.002 | |
| Max Weight of Workpiece | lb | 4400 |
| Maximum Speed | RPM | 1000 |
| Weight | lb | 75 |
| Diameter D | in | 11.5 |
| Minimum Point Diameter A | in | 7.09 |
| Projection Length B | in | 4.57 |
| Head Length C | in | 4.21 |
| Overall Length L | in | 11.73 |
