Mitutoyo Digital Micrometer IP65 250-275mm, with Output - 293-256-30
Brand: Mitutoyo- SKU:
- 293-256-30
- ID:
- 365943
| Mitutoyo Model | 293-256-30 |
| Range | 250 - 275 mm |
| Thimble | Ratchet Stop |
| Accuracy | ± 0.004 mm |
| Output | Yes |
$718.30
Mitutoyo Digital Micrometer IP65 250-275mm, with Output - 293-256-30
This IP65 micrometer offers outstanding accuracy, without data output, is highly robust and offers the following benefits:
- Oil-resistant material used for all plastic parts
- Extraordinary battery life of 2,4 years*
- Excellent resistance against water and dust enables this micrometer to be used in machining situations that include splashing coolant fluid.
Specifications:
| Accuracy | ±4 µm |
| Flatness | 0,3 µm |
| Data output | Yes |
| Mass | 1340 g |
| Range | 250-275 mm |
| Digital step | 0,001 mm |
| Measuring surfaces | Carbide-tipped, micro-lap finish |
| Battery life | Approx. 2,4 years for models ≤100 mm 1,2 years for >100 mm |
| Delivered | Including box, key, 1 battery, setting standard (from 25 mm upward) certificate of inspection (0-50 mm range) |
| ORIGIN (until 100 mm) | Yes |
| ZERO/ABS | Yes |
| Auto Power OFF after 20 min. non use | Yes |
| Function lock | Yes |
| HOLD | Yes |
| 2 x PRESET (over 100 mm) | Yes |
| Low voltage alarm | Yes |
| Digital/Analog | Digital |
| Inch-Metric | Metric |
| Scale | Thimble and sleeve satin chrome finish, ø18 mm |
| Parallelism | 5 µm |
| Measuring spindle | With spindle lock, ø6,35 mm, spindle pitch 0,5 mm |
| L | 250 |
| a | 18 |
| b | 152 |
| c | 6.5 |
See all Mitutoyo IP65 Digimatic Coolant-Proof Micrometers, Metric
