Samchully MCA Series Stationary Pneumatic Chuck, 8" Size - MCA-08
Brand: Samchully- SKU:
- MCA-08
- ID:
- 895468
| Size | 8" |
Samchully MCA Series Stationary Pneumatic Chuck, 8" Size - MCA-08
The Samchully MCA Stationary Pneumatic Chuck is designed for precision clamping in automated machining cells, milling fixtures, and rotary transfer systems. Its compact, low-profile design makes it ideal for integration into horizontal and vertical machining centers, as well as custom workholding setups that require repeatable, high-accuracy clamping without manual intervention.
Product Features:
The MCA-08 features a compact, low-profile design with a built-in pneumatic cylinder, eliminating the need for an external actuator and simplifying installation. It delivers a 33 kN clamping force with a 6.3 mm jaw stroke, providing reliable, repeatable holding across a Ø30–Ø210 mm chucking range. Built from hardened, precision-ground components, it ensures durability and consistent performance, while the flat base and multiple bolt patterns allow easy integration into fixtures, tombstones, or rotary tables.
Specifications:
View all specifications: MCA Series Stationary Pneumatic Chuck Specifications
| Model | MCA-08 |
| Clamping Force (Pneumatic 6Bar) [kN(kgf)] | 33(3300) |
| Jaw Stroke Dia. [mm] | 6.3 |
| Grip Dia. Max [mm] | 210 |
| Grip Dia. Min [mm] | 30 |
| Max. Pneumatic Pressure [MPa (kgf/cm²)] | 0.7 (7) |
| Weight [kg] | 28 |
